The Copper Clad Steel Conductor is used as flexible connector in electric transmission and distribution appliance (such as volt transformer, electric stove),electronic equipment and thyristor. Underground Electrical Wire also could be used for grounding wire in electric working. Also, it can be manufactured according to customer's drawings and demands.
| Material | copper clad steel |
| Diameter | 16～300 mm2 |
| Conductivity | 20%, 25%, 30%, 40% |
| Life | ≥30 years |
| Tensile Strength | 240-360 mpa |
| Characters | Easy installation ,Good conductivity |
| Available service mode | OEM,ODM |
| Certificate | ISO9001:2008 |
|
Product specifications |
Area (㎜2) |
Wire Dia×Nos (mm) |
Outer Dia (mm) |
Conduc tivity (%) |
Copper thickness (mm) |
Conduc tivity (%) |
Copper thickness (mm) |
Conduc tivity (%) |
Copper thickness (mm) |
Conduc tivity (%) |
Copper thickness (mm) |
|
CCSEP-S16/7 |
16 |
1.7×7 |
5.1 |
20 |
0.020 |
25 |
0.045 |
30 |
0.074 |
40 |
0.130 |
|
CCSEP-S25/7 |
25 |
2.14×7 |
6.5 |
20 |
0.025 |
25 |
0.058 |
30 |
0.093 |
40 |
0.165 |
|
CCSEP-S35/7 |
35 |
2.52×7 |
7.6 |
20 |
0.030 |
25 |
0.069 |
30 |
0.109 |
40 |
0.195 |
|
CCSEP-S50/19 |
50 |
1.8×19 |
9.0 |
20 |
0.021 |
25 |
0.049 |
30 |
0.078 |
40 |
0.139 |
|
CCSEP-S50/7 |
3.0×7 |
0.036 |
0.082 |
0.130 |
0.232 |
||||||
|
CCSEP-S70/19 |
70 |
2.14×19 |
11.0 |
20 |
0.025 |
25 |
0.058 |
30 |
0.093 |
40 |
0.165 |
|
CCSEP-S70/7 |
3.5×7 |
0.042 |
0.096 |
0.152 |
0.270 |
||||||
|
CCSEP-S95/19 |
95 |
2.52×19 |
12.6 |
20 |
0.030 |
25 |
0.069 |
30 |
0.109 |
40 |
0.195 |
|
CCSEP-S120/19 |
120 |
2.84×19 |
14.0 |
20 |
0.034 |
25 |
0.078 |
30 |
0.125 |
40 |
0.219 |
|
CCSEP-S150/37 |
150 |
2.28×37 |
16.0 |
20 |
0.027 |
25 |
0.062 |
30 |
0.099 |
40 |
0.176 |
|
CCSEP-S150/19 |
3.15×19 |
0.038 |
0.087 |
0.137 |
0.243 |
||||||
|
CCSEP-S185/37 |
185 |
2.52×37 |
17.6 |
20 |
0.030 |
25 |
0.069 |
30 |
0.109 |
40 |
0.195 |
|
CCSEP-S185/19 |
3.52×19 |
0.042 |
0.096 |
0.152 |
0.270 |
||||||
|
CCSEP-S240/37 |
240 |
2.88×37 |
20.0 |
20 |
0.034 |
25 |
0.079 |
30 |
0.127 |
40 |
0.220 |
|
CCSEP-S240/19 |
4.0×19 |
0.048 |
0.110 |
0.174 |
0.309 |
||||||
|
CCSEP-S300/37 |
300 |
3.2×37 |
22.4 |
20 |
0.038 |
25 |
0.088 |
30 |
0.139 |
40 |
0.247 |
Copper Clad Steel Conductor is used for earthing system of power plant ,transformer station ,tower ,communication station ,airport, railway, subway station , high building ,computer room ,petro plant ,oil reservoir in the environmental of moist ,saline and alkaline ,acid and chemical corrosion medium environmental.
All of our products are with strong packing and free of charge, we also can provide packing according to customer’s requirement.
